Our USA Made 37° Degree Female hosing is made of high quality materials that are built to last. Our USA Made hosing is constructed of a black carbon static dissipate Teflon hose. The smooth bore hose is constructed of an extruded inner-core of carbon black static dissipative PTFE with type 304 stainless steel wire braid reinforcement. The braid acts as a pressure carrier and protective covering. This smooth bore hose is found in many of the toughest service applications, handling “problem” fluids such as acids, solvents, fuels, and chemicals of all types.
Don't cheap out when it comes to hosing. Upgrade today and see the difference of our high quality USA Made hose.
|
3/8" Specification |
|
|
Connection |
3/8" 37° Female JIC Swivel |
|
Liner Material |
PTFE (Teflon) |
|
Braid Material |
304 Stainless Steel |
|
Maximum Working Pressure |
2500 PSI |
|
Minimum Burst Pressure |
10000 PSI |
|
Minimum bend Radius |
3.9" |
|
Temperature Rating |
-65° F (-54°C) to +450°F (+230°C) |
|
Actual ID |
.32" |
|
Actual OD |
.40" |
|
Application |
|
Chemical and Acid Transfer |
|
Pharmaceuticals |
|
Food Products |
|
Steam Lines/Tire Presses |
|
High Temperature Hydraulic/ |
|
Air Applications |
|
Pulp and Paper |
|
Fuel and Lubricant |
|
Glass Manufacturing |
|
Waste Water or Slurry 1 |
|
Benefits |
|
High working and burst pressures. |
|
Most economical of all hoses lined with PTFE |
|
The low-friction surface of smooth bore |
|
Hose provides for high flow rates |
|
Easily drained and/or cleaned |
|
Temperature Rating: 65° F (-54°C) to+450°F (+230°C) |
